CNC drilling and milling center with dowels

FELDER CREATOR 950 PREMIUM

CNC through-feed center with dual clamp drive in X-direction and gantry design in Y-direction. The second gripper enables trimming down to 15 mm as well as continuous milling movement along the X-axis.

The workpiece length is measured (X-direction) via sensor measurement.

Working area:
X-axis: 3,500 mm
Y-axis: 950 mm
Z-axis: 80 mm

Milling spindle 12 kW HSK-F63, up to 24,000 rpm max.

4-position linear tool changer for milling tools.
Max. tool diameter: 120 mm
Max. tool length: 100 mm

Single pick-up station for ergonomic insertion or removal of tools into the machine. Additionally usable as extra tool positions for up to 11 virtual tools.

Automatic length measuring system for tools in Z-direction.

Drilling head DH 25 8H 1S
- 17 vertical spindles
- 8 horizontal spindles
- Grooving saw in X-direction

Dowel insertion unit with 2 tools
Dowel diameter: 8 mm, lengths: 20-25-30-35 or 40 mm

Redpfxsxrahco Af Uobt
Air cushion tables at front and rear, foldable

Machine software WOODFLASH with:
- CNC Board (general machine operation)
- Tool database (Tecno-Manager)
- Programming editor

External workstation license

Dongle upgrade: 3D simulator with collision check for WOODFLASH at the machine

Release of workpiece at the rear side of the machine

Machine is supplied without tools and HSK holders
