Thermoforming machine - edge bander

Artex VPF2 3D

The VPF series vacuum press is designed for laminating with PVC foil as well as veneering with natural wood veneer. It is suitable for both small and large manufacturing facilities.

The VPF Vacuum Press is fully automated and features three operating modes:
- Automatic Mode: After pre-setting the working parameters on the PLC controller, the press automatically performs all actions (heating, pressing, cooling).
- Manual Mode: The operator manually carries out all operations.
- Membrane Mode: Intended for use with a membrane for veneering and laminated bending (also available in automatic mode).

Working area: 1400x3000 mm
Lodpfx Agjxpqt Djneah
Max temperature: 140°C
Power: 30 kW
Power supply: 3P 400V 50Hz
Dimensions: 3500x1700x2200 mm
Weight: 1150 kg

APPLICATIONS:
- Laminating flat components with PVC foil (kitchen fronts, window sills)
- Veneering straight and shaped elements with natural wood veneer (doors, frames, chairs, tables, furniture, coffins)
- Laminating components with HPL laminates in 2D format (kitchen countertops, window sills)
- Pressing of structured surfaces (stone veneer, decorative mats)

CONSTRUCTION:
- Robust welded frame, powder-coated
- Infrared heating system with carbon heaters
- Three heating zones with adjustable temperature
- Pneumatic cylinders for lifting the heating dome
- All-round access to the working table
- Integrated PLC controller for automated operation
- Equipped with an electronic vacuum control system
- Working table surface made from HPL board
- Built-in oil-lubricated vacuum pump (100 m³) – 0.9-0.95 bar (9000-9500 kg/m²)
- Integrated 100-litre buffer tank
- Upper heating dome made of aluminum
