Injector

Arburg 221 K 350 - 100 U

Injection moulding machine Arburg 221 K 350 - 100 U
Year of manufacture: 2001
Control type: Selogica
Closing system: Knee
TECHNICAL DATA
Closing force: 350 kN
Clearance between columns: 221 mm
Plate dimensions: 324 mm x 250 mm
Mould size: min. 150 mm - 300 mm
Maximum opening distance: 200 mm
Max distance between plates: 500 mm
Screw diameter: 20 mm
Injection volume / Injection weight: 31 ccm / 26 grams PS
Injection pressure: 2500 bar
GENERAL DATA
Crodpfx Agep At Rdogjh
Engine: 7.5 kW
Heaters: 4.5 kW
Operating hours: On request
Dimensions L x W x D: 2.7 m x 1.4 m x 2.2 m
Weight: 1060 kg
