Panel saw

Holzma Profi HPL 380/43/22

Used horizontal panel saw

Manufacturer: Holzma
Model: PROFI HPL 430/43/22
Year of manufacture: 2011

Cutting length: 4300 mm
Cutting width (program pusher travel): 4250 mm
Roller rail (double track): 9 pieces
Ncedpfx Aoymx S Ded Tsn
Clamps: 7 pieces, first 3 are 2-fingered
Air cushion table, width 650 mm: 4 pieces, each 2160 mm long
Central blower: 1 unit with increased air output

- 3 angled lift clamps (2-fingered)
- 1 angled lift clamp (1-fingered)
- 1st air cushion table: 800 mm wide
- Speed package: -> Saw carriage feed: 1 – 150 m/min

Technical specifications:
Blade projection: 95 mm
Saw carriage feed: forwards 25 m/min, reverse constant 90 m/min
Automatic cutting height adjustment
Angle pressure device, min. pressure width 0 mm; max. pressure width full cutting length
Main saw motor: 18 kW, frequency controlled
Scorer saw motor: 2.2 kW
Operating voltage: 400 V (+10%/-5%) / 50 Hz
Electrical connection value with HS motor 18 kW: 28 kW
Power Control CADmatic 4.0 control unit with 17" flat display
Labeling with part graphics / label software / label printer PICA 104
