CNC Machining Center

Alzmetall GX 1000/5 - FDT

A CNC 5-axis portal machining center Alzmetall with milling-turning table is available. Travel X/Y/Z: 800mm/800mm/600mm, B-axis swivel: +/-120°, C-axis rotation: 360°, table diameter: 630mm, max. table load: 1000kg, tool holder: HSK-A63, spindle speed: 12000rpm, tool positions: 33, max. workpiece diameter: 90mm/125mm, max. tool length: 300mm, max. tool weight: 8kg, rapid traverse: 60m/min, feed rate: 30m/min. Machine dimensions: approx. 3700mm/3000mm/3200mm, weight: approx. 15500kg. Documentation available. An on-site inspection is possible.
