Travelling column milling machine

Soraluce FL8000

Soraluce model FL8000 high performance travelling column, floor type CNC milling machine
TRAVEL (X) 7,500 mm
TRAVEL (Y) 1,400 mm
TRAVEL (Z) 1,000 mm
RAPID TRAVERSE (X,Y,Z) 25,000 mm/min
WORKING FEED RANGE (X,Y,Z) 1 – 10,000 mm/min
ACCELERATION RATE (Instantaneous not maximum) 1 m/sec2
SPINDLE SPEED 20 - 4,000 Rpm
SPINDLE TAPER ISO 50
SPINDLE POWER 28 Kw

NC15C - HEIDENHAIN iTNC 530 (Flat 15.1" TFT Screen with digital drives). Single processor version. Prepared for a machine of 10 motors (9 CNC axes + spindle motor).
Main push button panel with individually operated push buttons for linear axes (X+, X-, Y+, Y-, Z+, Z-)
K20 smarT.NC option for the i530M.
Independent AC. Heidenhain digital drive servomotor for each axis
HEIDENHAIN HR-410 portable electronic handwheel with 5m spiral cable
Automatic Indexing head 28Kw, 760Nm, 0.001°x 0.001°, 4000 Rpm. Continuous air and oil mist lubrication system for head gears.
Automatic Tool Clamping device – 15,000N. Automatic hydraulic tool releasing device
Spindle taper: BT50
High Torque spindle motor 28kW, 100% ED, digital motor.
R10 – ZF gearbox two speed including cooling unit
Spindle Speed Range 20 – 4,000Rpm
Rapid Feed X-Y-Z axes 25.000mm/min
Working Feed range X-Y-Z axes 0 - 10.000mm/min
Acceleration rate X- Y -Z axes 1 m/s2 (instantaneous, not maximum)
Hydraulic counterbalance system for head/ram assembly
X axis driving system by two servomotors, two gearboxes and a double rack & pinion
Preloaded ballscrews with double recirculating nuts in Y and Z axes. Automatic centralized lubrication system.
Linear Guiding System with recirculating cylindrical rollers in each axis. Automatic centralized lubrication system for the guides.
HEIDENHAIN Linear measuring scales in X-Y-Z axes with compressed air purge system - (Precision +/- 0,005mm)
H48 – Coolant through the spindle type AD.
M3 – Automatic tool changer 40 stations.
M6 – Horizontal-vertical tool changing facility.
M8 – Motorized tool changing device. Tool changer is driven by a servo motor
Hydraulic equipment
Front metallic roller blind cover to both upper and lower ram area, together with metallic protection to the lateral side of the column, between the machine table and the rear guideway support, which protects the vertical movement of the ram.
CE10 - PROTECTION on the back and both lateral sides of the machine column
P20 - Operator's platform fixed to the column and travels together with it in the "X" axis direction. The main operator’s panel is mounted within the operator's platform area for machines without an operator’s pendant and is accessed from the rear of the machine.
D7 + D50A - Coolant system with 1000L capacity tank with two pumps providing high and low pressure providing 5 & 12bar and 50L/min flow rate. Paper and Magnetic filtering.
E30A – swarf conveyor FL8000 Hinge conveyor belt. Width 350mm
PW11B – Pendulum working area system.
PM2 x 2 – Machine prepared by Soraluce for the inclusion of two rotary tables.
Working area lighting.
Electrical cabinet cooling system
Electrical cabinet lighting
Working methods - According to CE safety regulations
Dcedsw U Tlzepfx Ahkei
Filter to assure electromagnetic compatibility.
Protection to both sides of the column with security bumpers
Anchoring Bolts
Standard Colour - Blue RAL 5005 / Grey RAL 7035
K19 – Two sets of machine documentation (One hard copy, one on CD ROM)
Floor plate 8,000 x 1,500 x 300mm
