DMG MORI CLX 350 V4

DMG MORI CLX 350 V4

This 4-axis DMG MORI CLX 350 lathe was manufactured in 2018. It features a maximum workpiece diameter of 320 mm and a maximum machining length of 530 mm. The machine is equipped with a Siemens SLIM Line CNC and offers an X-axis travel of 242 mm, Y-axis travel of +/- 40 mm, and Z-axis travel of 540 mm. If you are looking to get high-quality turning capabilities, consider the DMG MORI CLX 350 lathe we have for sale. Contact us for further details.

• Maximum workpiece diameter: 320 mm
• Maximum machining length: 530 mm
• Bar capacity: 65 mm
• Spindle hours: 236 h
• Maximum spindle speed: 5,000 rpm
• Spindle power: 16.5 kW
• Spindle torque: 168 Nm
• Y-axis: ±40 mm
• C-axis: Yes
• Driven tools: Yes
• Counter spindle: No
• Hydraulic tailstock
• 12-station VDI40 turret with driven tools
• 15" SlimLine operator panel
• Siemens SINUMERIK 840D SL CNC with ShopTurn
• USB and Ethernet connectivity
• SMW Autoblok BH-D 250/1220 hydraulic 3-jaw chuck
• Chuck diameter: 250 mm
• Chuck bore: 66 mm
Hsdpfx Aozx A Ilonijnu
• Hard and soft jaw sets included
• 12 VDI40 tool holders
• 6 Block Tool boring bar holders with internal coolant
• PROGRESSline & Planonlight functions, including cycle time display, remaining time display and parts counter
• Chip conveyor: No

Technical Specification
Counter Spindle No
Driven Tools Yes
