High-performance solid-state disk laser

Trumpf TruDisk 4002 (4 C)

Trumpf
TRUMPF TruDisk 4002 (4 C) High-Performance Solid-State Disk Laser with up to 4 kW Output
Type: TruDisk 4002 (4 C)
The TruDisk 4002 is a powerful, energy-efficient, and modular laser solution – ideal for industrial manufacturing environments with demanding requirements for quality, precision, and automation.
The combination of high power, excellent beam quality, and smart factory features makes it particularly attractive for modern production lines.
System type: TruDisk 4002 (4C)
Manufacturer: TRUMPF Laser GmbH + Co. KG
Year of manufacture: May 2012
Drawing number: 20-10-02-A3*
Crjdpfxowzahdj Abfsh
No additional tests were carried out in-house.
Operating hours could not be read out.
The laser operated flawlessly until decommissioning.

Technical features:
Output & wavelength: 80–4000 W at 1030 nm
Beam quality (BPP): typically 2 mm·mrad (up to 25 mm·mrad, depending on configuration)
Modular & compact: footprint < 1 m², modular design simplifies maintenance/service
Efficient energy & cooling systems: energy-saving modes, active power factor correction, pulse function to reduce consumption
Flexible cooling: integrated heat exchanger (5–28 °C), optional with compressor (up to 38 °C inlet temperature)
Reflection-resistant: special resonator design also suitable for highly reflective metals
Industry 4.0 capable: extensive sensor technology and data interfaces for condition monitoring, OPC UA, predictive maintenance

Application areas:
Scanner & hybrid welding (e.g. automotive body manufacturing, shipbuilding)
High-speed cutting, including on reflective metals
Flame cutting & surface processing
Laser cladding, hardening, deep penetration welding where high precision is required

Technical data:
Supply voltage: 380 V (-10%) to 460 V (+10%), 3AC + PE
Frequency: 50 – 60 Hz
Power consumption: 23 kW / 25 kVA
Rated current: 34 A at 400 V
Protection rating: IP 54
Short-circuit strength: Icn / SCCR 50 kA
Weight: 850 kg
Condition: used
Scope of delivery: (See picture)
(Specifications subject to change and errors excepted!)
We would be happy to answer any further questions by phone.
