Blow molding machine

Eurodac EDA M600

Automatic PET Blow Molding Machine – 4 Cavities – 3,500–4,000 bottles/hour

Automatic PET preform blow molding machine with automatic feeding system, suitable for bottles up to 0.6 L.

Pjdpfx Akeyhh Nujujgr
Technical specifications
Number of cavities: 4
Production capacity: 3,500–4,000 pcs/hour
Maximum bottle volume: 0.6 L
Neck diameter: 38 mm
Maximum bottle diameter: 65 mm
Maximum bottle height: 230 mm
Heating system: 35 lamps
Average power consumption: 22 kW
Low-pressure air consumption: 1,600 L/min
Blowing pressure: 25–35 kg/cm²
High-pressure air consumption: 2,500 L/min
Chiller included
Cooling capacity: 5,600 kcal/h
Water flow: 30 L/min
Dimensions & Weight
Dimensions (L × W × H): 3.70 × 1.95 × 2.10 m
Weight: 3,700 kg

The machine is supplied with an automatic preform feeding system and chiller.

Suitable for high-output production of PET bottles and containers up to 600 ml.

For additional technical information, availability, price or further details, please contact us.
